Outdoor Unit Functions
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Discharge Temperature Control / Inverter Protection Control
Temperature Range Compressor Subcooling EEV Indoor Unit EEV
Tdis > 235.4°F -5 Hz / 10 seconds SC, SH Decrease Control SH Decrease Control
Tdis > 230°F -5 Hz / 10 seconds SC, SH Decrease Control SH Decrease Control
7GLV) Frequency Hold* SC, SH Decrease Control SH Decrease Control
7GLV) +]RUOHVV SC, SH Decrease Control SH Decrease Control
Tdis > 212°F Normal Control SC, SH Decrease Control SH Decrease Control
Discharge Temperature Control
Table 16: Outdoor Unit Discharge Temperature Control.
* Frequency Hold = Frequency (or RPM) is not
increasing (can decrease).
Tdis = Temperature Discharge.
SC = Subcooling.
SH = Superheating.
PROTECTION CONTROL
Inverter Compressor Protection Control
The tables below display the amperage where the system will operate normally, the amperage where the inverter protection control will cause
the frequency to drop, and the amperage where the inverter protection control will shut the system off. AC input current is measured at the
inverter compressor (after the point where the current passes through the noise filter).
Table 17: Inverter Protection Control for 208-230V Outdoor Units (ARUM***BTE5).
1
$&LQSXWFXUUHQWLVWKHLQYHUWHUFRPSUHVVRULQSXWFXUUHQWH[FHSWFRQVWDQWFXUUHQWFXUUHQWSDVVLQJWKURXJKWKHQRLVH¿OWHU
Current Type Chassis Tons
Compressor
(HP)
Cooling & Heating
Normal System
Operation
Frequency Will Drop
System Will Stop
Operation
Comp. 1 Comp. 2 Comp. 1 Comp. 2 Comp. 1 Comp. 2
AC Input
Current
1
ARUM072DTE5 6 4.8 18A or less - 18A or more - 20A or more -
ARUM096DTE5 8 6.8 25A or less - 25A or more - 27A or more -
ARUM121DTE5 10 6.8 25A or less - 25A or more - 27A or more -
ARUM144DTE5 12 4.8 / 4.8 18A or less 17A or less 18A or more 17A or more 20A or more 19A or more
ARUM168DTE5 14 4.8 / 4.8 18A or less 17A or less 18A or more 17A or more 20A or more 19A or more
ARUM192DTE5 16 6.8 / 6.8 25A or less 25A or less 25A or more 25A or more 27A or more 27A or more
ARUM216DTE5 18 6.8 / 6.8 25A or less 25A or less 25A or more 25A or more 27A or more 27A or more
ARUM241DTE5 20 6.8 / 6.8 25A or less 25A or less 25A or more 25A or more 27A or more 27A or more
Compressor
Current
ARUM072DTE5 6 4.8 20A or less - 20A or more - 30A or more -
ARUM096DTE5 8 6.8 29A or less - 29A or more - 41A or more -
ARUM121DTE5 10 6.8 29A or less - 29A or more - 41A or more -
ARUM144DTE5 12 4.8 / 4.8 20A or less 20A or less 20A or more 20A or more 30A or more 30A or more
ARUM168DTE5 14 4.8 / 4.8 20A or less 20A or less 20A or more 20A or more 30A or more 30A or more
ARUM192DTE5 16 6.8 / 6.8 29A or less 29A or less 29A or more 29A or more 41A or more 41A or more
ARUM216DTE5 18 6.8 / 6.8 29A or less 29A or less 29A or more 29A or more 41A or more 41A or more
ARUM241DTE5 20 6.8 / 6.8 29A or less 29A or less 29A or more 29A or more 41A or more 41A or more
Table 18: Inverter Protection Control for 460V Outdoor Units (ARUM***DTE5).
Current
Type
Chassis Tons
Compressor
(HP)
Cooling & Heating
Normal System
Operation
Frequency Will Drop
System Will Stop
Operation
Comp. 1 Comp. 2 Comp. 1 Comp. 2 Comp. 1 Comp. 2
AC Input
Current
1
ARUM072BTE5 6 4.8 33A or less - 33A or more - 35A or more -
ARUM096BTE5 8 6.8 37A or less - 37A or more - 40A or more -
ARUM121BTE5 10 6.8 37A or less - 37A or more - 40A or more -
ARUM144BTE5 12 4.8 / 4.8 33A or less 33A or less 33A or more 33A or more 35A or more 35A or more
ARUM168BTE5 14 4.8 / 4.8 33A or less 33A or less 33A or more 33A or more 35A or more 35A or more
ARUM192BTE5 16 6.8 / 6.8 37A or less 37A or less 37A or more 37A or more 40A or more 40A or more
ARUM216BTE5 18 6.8 / 6.8 37A or less 37A or less 37A or more 37A or more 40A or more 40A or more
ARUM241BTE5 20 6.8 / 6.8 37A or less 37A or less 37A or more 37A or more 40A or more 40A or more
Compressor
Current
ARUM072BTE5 6 4.8 36A or less - 36A or more - 46A or more -
ARUM096BTE5 8 6.8 49A or less - 49A or more - 60A or more -
ARUM121BTE5 10 6.8 49A or less - 49A or more - 60A or more -
ARUM144BTE5 12 4.8 / 4.8 36A or less 36A or less 36A or more 36A or more 46A or more 46A or more
ARUM168BTE5 14 4.8 / 4.8 36A or less 36A or less 36A or more 36A or more 46A or more 46A or more
ARUM192BTE5 16 6.8 / 6.8 49A or less 49A or less 49A or more 49A or more 60A or more 60A or more
ARUM216BTE5 18 6.8 / 6.8 49A or less 49A or less 49A or more 49A or more 60A or more 60A or more
ARUM241BTE5 20 6.8 / 6.8 49A or less 49A or less 49A or more 49A or more 60A or more 60A or more
