INSTALLER’S SETTING OPTIONS
175
ENGLISH
174
INSTALLER’S SETTING OPTIONS
Zone Type Setting(air conditioner)
This function is only available on some products.
It is possible to setup zone new type or old one of the product which is available to install the
damper controller.
● Press and hold ‘wireless remote controller signal receiver part’ of the remote controller for
3seconds or longer to enter the installer function.
● Select remote controller Zone type setting code value ‘13’.
- You can press ‘▲’, ‘▼’ button to change the code value.
● In value1, use ‘▲’, ‘▼’ button to select Celsius control unit setting value, and press ‘Done’
button to complete the Zone type setting.
- If you do not press ‘Done’ button, the setting value will not be applied.
h Setting value
- 000 : Old
- 001 : New(4Zone)
- 002 : New(8Zone)
h If there is no button input for about 60 seconds after the setting, it automatically exits from the
setting mode.
Zone Number Setting(air conditioner)
This function is only available on some products.
Zone Number is to set the number of installed zones. It's possible to control only in zone new
type.
● Press and hold ‘wireless remote controller signal receiver part’ of the remote controller for
3seconds or longer to enter the installer function.
● Select remote controller Zone Number setting code value ‘14’.
- You can press ‘▲’, ‘▼’ button to change the code value.
● In value1, use ‘▲’, ‘▼’ button to select Celsius control unit setting value, and press ‘Done’
button to complete the Zone Number setting.
- If you do not press ‘Done’ button, the setting value will not be applied.
h Setting value
- 002~004 : Installed number(Zone type New[4Zone])
- 002~004 : Installed number(Zone type New[8Zone])
h If there is no button input for about 60 seconds after the setting, it automatically exits from the
setting mode.
