Liebert NX User Manual

UPS Specifications
36 Liebert
®
NX
™
6.0 UPS SPECIFICATIONS
These specifications describe requirements for the Liebert NX UPS.
6.1 Conformity and Standards
The UPS has been designed to conform to the following standards:
• UL Standard 1778
• CSA 22.2, No. 107.1
• FCC Part 15, Class A
• IEC 61000-4-5
• National Electrical Code (NFPA-70)
• NEMA PE-1
•ISTA_1H
The UPS shall be UL and cUL listed per UL Standard 1778.
6.2 UPS Environmental
The UPS is designed to operate under the following environmental conditions without damage or
degradation in electrical operating characteristics.
6.3 UPS Mechanical Characteristics
Table 6 Environmental characteristics
Rated Power
40kVA 60/80kVA 100/120kVA 160/200kVA
Operating Temperature, UPS 32°F to 104°F (0°C to 40°C)
Optimal Operating Temperature, Battery 68°F to 86°F (20°C to 30°C)
Relative Humidity 0 to 95%, non-condensing
Accoustical Noise, dBA at 39 in. (1m)
(fans at low speed)
61 61 63 68.5
Altitude of Operation
Up to 6562 ft. (2000m) above mean sea level without derating. Linearly
derated from 100% load at 6,562 ft. (2000m) to 88% load at 9843 ft. (3000m)
Storage-Transport Temperature, UPS, -4°F to 158°F (-25°C to 70°C)
Storage-Transport Temperature, Battery -4°F to 86°F (-20°C to 33°C)
Table 7 UPS mechanical characteristics
Parameter 40 kVA 60kVA 80kVA 80kVA 100kVA 120kVA 160kVA 200kVA
Dimensions, W x D x H, inches (mm)
All Units
25.5 x 39.0 x 78.7
(648 x 978 x 2000)
—— — — —
Units for use
with Liebert BDC
———
25.5 x 39.0 x 78.7
(648 x 978 x 2000)
48.8 x 39.0 x 78.7
(1239 x 978 x 2000)
Units with Wiring
Cabinet Extension
———
41.0 x 39.0 x 78.7
(1041 x 978 x 2000)
64.4 x 39.0 x 78.7
(1636 x 990 x 2000)
Weight, lb (kg)
All Units 1290 (585) — —
For use with Liebert BDC — 1422 (645) 2201 (998)
Includes Wiring Cabinet Extension — 1847 (837) 2626 (1191)
Heat Dissipation, BTU/H (kWH)
12,200
(3.6)
15,400
(4.5)
20,600
(6.0)
19,700
(5.8))
24,300
(7.1)
28,700
(8.4)
35,900
(10.5)
47,00
(13.8)
Airflow, CFM (m
3
/h)
620
(1050)
620
(1050)
620
(1050)
1668
(2834)
920
(1550)
920
(1550)
1590
(2700)
1590
(2700)
Cable Entry Bottom or Top
Color Black (ZP-7021)
Protection Grade
(with open/closed front doors)
IP 20

Liebert NX Specifications

General

Frequency	50/60 Hz
Topology	Double Conversion/Online
Input Voltage	208, 220, 240 VAC
Output Voltage	208, 220, 240 VAC
Battery Type	VRLA
Operating Temperature	0 to 40°C (32 to 104°F)
Humidity Range	0 to 95% (non-condensing)
