Table 17 Circuit breaker schedule - Main circuit breaker
kVa Voltage In Vendor Frame Amps Trip Amps Model Number
Interrupting
Rating AIC
15
208V
ABB
250A 60A T4S060TW-S24 100K
240V 250A 50A T4S050TW-S24 100K
380V 250A 30A T4S030TW-S24 35K
400V 250A 30A T4S030TW-S24 35K
415V 250A 30A T4S030TW-S24 35K
480V 250A 25A T4S025TW-S24 35K
600V 250A 20A T4S020TW-S24 25K
30
208V
ABB
400A 110A T4S110TW-S24 100K
240V 400A 100A T4S100TW-S24 100K
380V 250A 60A T4S060TW-S24 35K
400V 250A 60A T4S060TW-S24 35K
415V 250A 60A T4S060TW-S24 35K
480V 250A 50A T4S050TW-S24 35K
600V 250A 40A T4S040TW-S24 25K
50
208V
ABB
600A 200A T4S200TW-S24 100K
240V 400A 175A T4S175TW-S24 100K
380V 250A 100A T4S100TW-S24 35K
400V 250A 100A T4S100TW-S24 35K
415V 250A 90A T4S090TW-S24 35K
480V 250A 80A T4S080TW-S24 35K
600V 250A 70A T4S070TW-S24 25K
75
208V
ABB
600A 300A T5S300TW-S24 100K
240V 600A 250A T4S250TW-S24 100K
380V 400A 150A T4S150TW-S24 35K
400V 400A 150A T4S150TW-S24 35K
415V 400A 150A T4S150TW-S24 35K
480V 250A 125A T4S125TW-S24 35K
600V 250A 100A T4S100TW-S24 25K
100
208V
ABB
250A 400A T5S400TW-S24 100K
240V 250A 350A T5S350TW-S24 100K
380V 250A 200A T4S200TW-S24 35K
400V 250A 200A T4S200TW-S24 35K
415V 250A 200A T4S200TW-S24 35K
480V 250A 175A T4S175TW-S24 35K
600V 250A 125A T4S125TW-S24 25K
125
208V
ABB
250A 450A T5S450BW-S24 100K
240V 250A 400A T5S400BW-S24 100K
380V 250A 250A T4S250TW-S24 35K
400V 250A 250A T4S250TW-S24 35K
415V 250A 225A T4S225TW-S24 35K
480V 250A 200A T4S200TW-S24 35K
600V 250A 175A T4S175TW-S24 25K

Liebert NX Specifications

General

Frequency	50/60 Hz
Topology	Double Conversion/Online
Input Voltage	208, 220, 240 VAC
Output Voltage	208, 220, 240 VAC
Battery Type	VRLA
Operating Temperature	0 to 40°C (32 to 104°F)
Humidity Range	0 to 95% (non-condensing)
