Installation Drawings
Liebert
®
NX
™
71
Figure 45 Liebert NX 480V paralleling cabinet main components—input, bypass and distribution circuit
breaker configuration
Front
With Covers
Bypass
Tie
Breaker
Bypass
Tie
Breaker
Ground
Bus
UPS Input
System Input
Front
Without Covers
Rear
With Covers
Rear
Without Covers
UPS
Output
Output
Distribution
