Liebert NX User Manual

Liebert BDC
™
48 Liebert
®
NX
™
Table 20 Subfeed circuit breaker
kVA
Voltage
In Vendor Type
Frame
Amps
Trip
Amps
Model
Number
Interrupting
Rating AIC
15-300 208V ABB FIX MTD 250A 100A T4N100TW 65K
15-300 208V ABB FIX MTD 250A 125A T4N125TW 65K
15-300 208V ABB FIX MTD 250A 150A T4N150TW 65K
15-300 208V ABB FIX MTD 250A 175A T4N175TW 65K
15-300 208V ABB FIX MTD 250A 200A T4N200TW 65K
15-300 208V ABB FIX MTD 250A 225A T4N225TW 65K
15-300 208V ABB FIX MTD 250A 250A T4N250TW 65K
150-300 208V ABB FIX MTD 400A 300A T5N300TW 65K
150-300 208V ABB FIX MTD 400A 350A T5N350TW 65K
150-300 208V ABB FIX MTD 400A 400A T5N400TW 65K
Table 21 Square D I-Line panelboard circuit breaker
kVA
Voltage
In Vendor Type
Frame
Amps
Trip
Amps
Model
Number
Interrupting
Rating AIC
50-300 208V SQUARE D PLUG-IN 150A 100A HGA36100 65K
50-300 208V SQUARE D PLUG-IN 150A 125A HGA36125 65K
50-300 208V SQUARE D PLUG-IN 150A 150A HGA36150 65K
50-300 208V SQUARE D PLUG-IN 250A 175A JGA36175 65K
50-300 208V SQUARE D PLUG-IN 250A 200A JGA36200 65K
50-300 208V SQUARE D PLUG-IN 250A 225A JGA36225 65K
50-300 208V SQUARE D PLUG-IN 250A 250A JGA36250 65K
225-300 208V SQUARE D PLUG-IN 400A 300A LA36300 42K
225-300 208V SQUARE D PLUG-IN 400A 350A LA36350 42K
225-300 208V SQUARE D PLUG-IN 400A 400A LA36400 42K

Liebert NX Specifications

General

Frequency	50/60 Hz
Topology	Double Conversion/Online
Input Voltage	208, 220, 240 VAC
Output Voltage	208, 220, 240 VAC
Battery Type	VRLA
Operating Temperature	0 to 40°C (32 to 104°F)
Humidity Range	0 to 95% (non-condensing)
