Figure 31 Liebert NX 160-200kVA dimensional view—front and left side
FRONT VIEW LEFT VIEW
1239mm (48.8")
979mm (38.5")
2000mm
(78.7")
1000mm
(39.4")
610mm (24")
590mm 23.2"
