Installation Drawings
70 Liebert
®
NX
™
Figure 44 Liebert NX 480V paralleling cabinet with input and bypass circuit breakers, main components
Front
Rear
System Output
Tie Breaker
Kirk - Key
Fuse
Disconnect
System
Output
Busbar
Ground
Busbar
UPS Output
Breaker
System
Bypass
Tie Breaker
UPS
Input
Breakers
System
Input
