Installation Drawings
58 Liebert
®
NX
™
Figure 32 Liebert NX 160-200kVA dimensions continued—top and bottom view
BOTTOM VIEW
TOP VIEW
Front of UPS
Front of UPS
1239mm (48.77")
972mm
(38.28")
1239mm (48.77"
842mm
(33.14")
1110mm (43.72")
A
Detail A
355mm
(13.99")
330mm
(12.99")
