2.2 Mounting of Wall Profiles with a vertical safety barrier
The Vertical Safety Barrier can be delivered as an add-on solution,
which can be fitted to an existing FlexStep V2, To do this you need
to change the wall profiles, as they are different.
2.2.1 Fixing the wall profiles on the wall
1.
Start by removing the plastic cover on the top of the left hand side wall profile.
Remove the 2 brush rails, and the aluminium cover rail.
2.
Start by checking the upper landing floor. If
the floor is not even, start fitting the wall
profile where the floor is lower (could be
the right hand side).
Make sure that the distance between the
top of the wall profile and the upper level is
precisely 1100 mm.
Make sure that you also have 20 mm free
space under the wall profile (use a piece of
wood or plastic shims).
If you cannot have 20 mm at the bottom,
you need to shorten the wall profile at the
bottom.
