Left hand girder
8.3 Removing the wires
Remove the step inserts on the lower step, upper step and step with control panel, for
easy access to the wires. Pull the disconnected wires through the bushings on the steps.
Remove cable binders where necessary
RH side girder
1. Actuator
2. Control Panel
3. IR Board
1. IR Board
2. Safety Switch
