3.4 Control Board LED signals
Control board (102352)
HB.
Yellow
H-BRO SUP
Yellow
H-BRO3 SUP
Yellow
OC. H-BRO3
Red
AC ON
Yellow
BATT. FLOAD
Yellow
EMS. OK
Green
H-BRO ON
Green
+3V3
Yellow
IR Platform
Green
IR Stairs
Green
Upper Gate SW.
Green
Lower Gate SW.
Green
Under Pan SW.
Green
+12V
Yellow
