7.3 Wiring of push buttons and emergency Stop
Emergency Stop
Button 100339
Speaker 103083
Background light
Platform up
Platform down
Platform up
Speaker
Background light
Emergency Stop
Button 100339
Platform down
Emergency
Stop (GND)
Emergency
Stop
