2 Attachment to building
2.1 Mounting of Wall Profiles without a vertical safety barrier.
If your FlexStep V2 is fitted with a vertical safety barrier – go to chapter
2.2.
The FlexStep V2 lifting platform/staircase is delivered almost fully
assembled. Only the two wall profiles need to be attached to the adjoining
wall to ensure a stable performance.
2.1.1 Fixing the wall profiles on the wall
Start by removing the plastic cover on the top of the left hand side wall profile.
Remove the protection profiles.
Start by checking the upper landing floor. If the
floor is not even, start fitting the wall profile
where the floor is lower (could be the right hand
side).
Make sure the distance between the top of the
wall profile and the upper level is precisely 820
mm
Make sure that you also have 20 mm free space
under the wall profile (use a piece of wood or
plastic shims).
If you cannot have 20 mm at the bottom, you
need to shorten the wall profile at the bottom.
