Lighthouse SOLAIR 3350 - Page 76

Lighthouse SOLAIR 3350, 5350 Gen E Operating Manual
6-12 248083387-1 Rev 10
Figure 6-11 Differential and Cumulative Data in Zoomed View
The buttons available when touching the data area of the screen after
selecting DiffCuml on Zoom are shown in Figure 6-12. Note the
selections are different but their functions are the same as on dual
display screen.
Figure 6-12 Diff / Cuml Screen Button Actions
START/STOP counting
Display Particle data or Analog data
PRINT the last record
Display Raw / Normalized particle data
Display ft
3
/ m
3
when configured
