LIGHTMED TruScan Pro – Operator’s Manual Rev. No. 01 Page 57 of 109
1.0
3 dots
3 dots
1.5
N/A
3 dots
11
Arc
pattern
Triple arc rings Double arc rings
• Triple arc rings parameters (rotation can be adjusted from 0 to 355° in 5°-
increments):
Spot Size (µm)
Spacing (Φ)
Radius (1,000 µm)
200
1.0
18 dots
1.5
15 dots
2.0
13 dots
300
1.0
13 dots
