LIGHTMED TruScan Pro – Operator’s Manual Rev. No. 01 Page 58 of 109
1.5
11 dots
2.0
9 dots
• Double arc rings parameters (rotation can be adjusted from 0 to 355° in 5°-
increments):
Spot Size (µm)
Spacing (Φ)
Radius (µm)
1,000
1,500
200
1.0
10 dots
14 dots
1.5
8 dots
12 dots
2.0
7 dots
10 dots
300
1.0
7 dots
10 dots
1.5
6 dots
