Lightware MMX8x4-HT Series


12. Appendix MMX8x4-HT series – User's Manual 186



Port name
Video port nr.
(LW2)
Video port nr.
(LW3)
Emulated
EDID memory
Audio port nr.
(LW2)
Audio port nr.
(LW3)
HDMI IN 1 01 I1 F47 - I1
HDMI IN 2 02 I2 F47 - I2
HDMI IN 3 03 I3 F47 - I3
HDMI IN 4 04 I4 F47 - I4
HDMI IN 5 05 I5 F47 - I5
HDMI IN 6 06 I6 F47 - I6
HDMI IN 7 07 I7 F47 - I7
HDMI IN 8 08 I8 F47 - I8
HDMI OUT 1 01 O1 - - O1
HDMI OUT 2 02 O2 - - O2
HDMI OUT 3 03 O3 - - O3
HDMI OUT 4 04 O4 - - O4
HDMI OUT 5 05 O5 - - O5
HDMI OUT 6 06 O6 - - O6
HDMI OUT 7 07 O7 - - O7
HDMI OUT 8 08 O8 - - O7
RS-232 Ports
Port name
Port nr.

Command
injection port nr.
Uart 1 P1 8001
Uart 2 P2 8002
Uart3 Mixed P3 8003
Uart4 Mixed P4 8004
Ethernet
Port name
Port nr.
(LW3)
CPU P1
Control P2


Port name
Video port nr.
(LW2)
Video port nr.
(LW3)
Emulated
EDID memory
Audio port nr.
(LW2)
Audio port nr.
(LW3)
HDMI IN 1 01 I1 F47 - I1
HDMI IN 2 02 I2 F47 - I2
HDMI IN 3 03 I3 F47 - I3
HDMI IN 4 04 I4 F47 - I4
HDMI IN 5 05 I5 F47 - I5
HDMI IN 6 06 I6 F47 - I6
HDMI IN 7 07 I7 F47 - I7
HDMI IN 8 08 I8 F47 - I8
HDMI OUT 1 01 O1 - - O1
HDMI OUT 2 02 O2 - - O2
HDMI OUT 3 03 O3 - - O3
HDMI OUT 4 04 O4 - - O4
HDMI OUT 5 05 O5 - - O5
HDMI OUT 6 06 O6 - - O6
HDMI OUT 7 07 O7 - - O7
HDMI OUT 8 08 O8 - - O7
RS-232 Ports
Port name
Port nr.

Command
injection port nr.
Uart 1 P1 8001
Uart 2 P2 8002
Uart3 Mixed P3 8003
Uart4 Mixed P4 8004




