Lightware MMX8x4-HT Series


4. Installation MMX8x4-HT series – User's Manual 31

Control Ethernet Port


both cable types (straight or cross) are supported and handled by the device, below pin assignment is
recommended.
Wiring of LAN Cables

standards.
LED1 green
on 
off 
LED2 amber
on no activity
off not linked
blinking activity
Top
Bottom
Side



compliant. See more information in Ethernet Interface section.

DIFFERENCE:  MMX8x4-HT400MC and MMX8x4-HT400M models have TPS connector.
Not PoE-compatible.

This model has four TPS inputs and two TPS outputs. PoE-compatible, each port can remote

INFO:  
IR Connector
IR emitter can be connected to the matrix switcher with TRS (Tip, Ring, and Sleeve) connectors. They

The pin assignments are the following :
Emitter – 2-pole-TS
1 Tip 
2 Ring
Signal (active low)
3 Sleeve
INFO:  Ring pole of the emitter is optional. If your IR emitter has three pole- TRS plug, then the Ring and the
Sleeve are the same signal (Output - ).
INFO:   Infra Interface section.




