12. Appendix MMX8x4-HT series – User's Manual 192
Factory EDID List
Mem. Resolution Scan type EDID type
F1 640 x 480 @ 60.00 p D
F2 848 x 480 @ 60.00 p D
F3 800 x 600 @ 60.32 p D
F4 1024 x 768 @ 60.00 p D
F5 1280 x 768 @ 50.00 p D
F6 1280 x 768 @ 59.94 p D
F7 1280 x 768 @ 75.00 p D
F8 1360 x 768 @ 60.02 p D
F9 1280 x 1024 @ 50.00 p D
F10 1280 x 1024 @ 60.02 p D
F11 1280 x 1024 @ 75.02 p D
F12 1400 x 1050 @ 50.00 p D
F13 1400 x 1050 @ 60.00 p D
F14 1400 x 1050 @ 75.00 p D
F15 1680 x 1050 @ 60.00 p D
F16 1920 x 1080 @ 50.00 p D
F17 1920 x 1080 @ 60.00 p D
F18 2048 x 1080 @ 50.00 p D
F19 2048 x 1080 @ 60.00 p D
F20 1600 x 1200 @ 50.00 p D
F21 1600 x 1200 @ 60.00 p D
F22 1920 x 1200 @ 50.00 p D
F23 1920 x 1200 @ 59.56 p D
F24 2048 x 1200 @ 59.96 p D
F29 1920 x 1080 @ 60.00 Hz p U
F30 1440 x 480 @ 60.05 i H
F31 1440 x 576 @ 50.08 i H
F32 640 x 480 @ 59.95 p H
F33 720 x 480 @ 59.94 p H
F34 720 x 576 @ 50.00 p H
Mem. Resolution Scan type EDID type
F35 1280 x 720 @ 50.00 p H
F36 1280 x 720 @ 60.00 p H
F37 1920 x 1080 @ 50.04 i H
F38 1920 x 1080 @ 50.00 i H
F39 1920 x 1080 @ 60.05 i H
F40 1920 x 1080 @ 60.05 i H
F41 1920 x 1080 @ 24.00 p H
F42 1920 x 1080 @ 25.00 p H
F43 1920 x 1080 @ 30.00 p H
F44 1920 x 1080 @ 50.00 p H
F45 1920 x 1080 @ 59.94 p H
F46 1920 x 1080 @ 60.00 p H
F47 1920 x 1080 @ 60.00 Hz p U
F48 1920 x 1080 @ 60.00 Hz p U
F49 1920 x 1080 @ 60.00 Hz p U
F90 1920 x 2160 @ 59.99 p D
F91 1024 x 2400 @ 60.01 p D
F94 2048 x 1536 @ 60.00 p D
F96 2560 x 1600 @ 59.86 p D
F97 3840 x 2400 @ 24.00 p D
F98 1280 x 720 @ 60.00 p H
F99 1920 x 1080 @ 60.00 p H
F100 1024 x 768 @ 60.00 p H
F101 1280 x 1024 @ 50.00 p H
F102 1280 x 1024 @ 60.02 p H
F103 1280 x 1024 @ 75.02 p H
F104 1600 x 1200 @ 50.00 p H
F105 1600 x 1200 @ 60.00 p H
F106 1920 x 1200 @ 59.56 p H
F107 2560 x 1440 @ 59.95 p H
F108 2560 x 1600 @ 59.86 p H
Mem. Resolution Scan type EDID type
F109 3840 x 2400 @ 24.00 p H
F110 3840 x 2160 @ 24.00 p H
F111 3840 x 2160 @ 25.00 p H
F112 3840 x 2160 @ 30.00 p H
F118 3840 x 2160 @ 30.00 Hz p U
F119 3840 x 2160 @ 30.00 Hz p U
F133 4096 x 2160 @ 60.00 p 4
Legend
D:
H: HDMI EDID
U: Universal EDID, supporting many standard resolutions:
▪ F29:
▪ F47: HDMI EDID supporting PCM audio.
▪ F48: HDMI EDID supporting all type of audio.
▪ F49: HDMI EDID supporting all type of audio and deep color.
▪ F89: Universal EDID for analog signals (no audio support).
▪ F118:
▪ F119:
signals.
Please note that minor changes in the factory EDID list may be applied
To Next Page
