7
Table 1: LMS7002Mr3 memory map
Logical
Block
Type
Logical Block
Name
Size,
regs
Cmd
(R/W)
Address
Comments
Resserved
[3:0]
Maddress
[4:0]
Reg
[5:0]
Other
uC
16
0/1
0000
00000
00xxxx
Address space starts at 0x0000. Addressing do not depend from MAC[1:0].
Lime Light
32
0/1
0000
00000
1xxxxx
Address space starts at 0x0020. Addressing do not depend from MAC[1:0].
DC Calibration
32
0/1
0000
10111
0xxxxx
Address space starts at 0x05C0. Addressing do not depend from MAC[1:0].
RSSI, PDET,
TEMP
Measurements
32
0/1
0000
11000
0xxxxx
Address space starts at 0x0600. Addressing do not depend from MAC[1:0].
TOP
Top Control (AFE,
BIAS, XBUF,
CGEN, LDO, BIST)
128
0/1
0000
0001x
xxxxxx
Address space starts at 0x0080. Addressing do not depend from MAC[1:0].
TRX
TRX (TRF(A/B),
TBB(A/B),
RFE(A/B),
RBB(A/B), SX(R/T)
128
0/1
0000
0010x
xxxxxx
Address space starts at 0x0100. Selected MIMO channel depends on MAC[1:0].
RSSI DC
Calibration
32
0/1
0000
11001
0xxxxx
Address space starts at 0x0640. Selected MIMO channel depends on MAC[1:0].
TX
TxTSP(A/B)
32
0/1
0000
01000
0xxxxx
Address space starts at 0x0200. Selected MIMO channel depends on MAC[1:0].
TxNCO(A/B)
64
0/1
0000
01001
xxxxxx
Address space starts at 0x0240. Selected MIMO channel depends on MAC[1:0].
TxGFIR1(A/B)
64
0/1
0000
01010
xxxxxx
Address space starts at 0x0280. Selected MIMO channel depends on MAC[1:0].
TxGFIR2(A/B)
64
0/1
0000
01011
xxxxxx
Address space starts at 0x02C0. Selected MIMO channel depends on MAC[1:0].
TxGFIR3a(A/B)
64
0/1
0000
01100
xxxxxx
Address space starts at 0x0300. Selected MIMO channel depends on MAC[1:0].
TxGFIR3b(A/B)
64
0/1
0000
01101
xxxxxx
Address space starts at 0x0340. Selected MIMO channel depends on MAC[1:0].
TxGFIR3c(A/B)
64
0/1
0000
01110
xxxxxx
Address space starts at 0x0380. Selected MIMO channel depends on MAC[1:0].
RX
RxTSP(A/B)
32
0/1
0000
10000
0xxxxx
Address space starts at 0x0400. Selected MIMO channel depends on MAC[1:0].
RxNCO(A/B)
64
0/1
0000
10001
xxxxxx
Address space starts at 0x0440. Selected MIMO channel depends on MAC[1:0].
RxGFIR1(A/B)
64
0/1
0000
10010
xxxxxx
Address space starts at 0x0480. Selected MIMO channel depends on MAC[1:0].
RxGFIR2(A/B)
64
0/1
0000
10011
xxxxxx
Address space starts at 0x04C0. Selected MIMO channel depends on MAC[1:0].
RxGFIR3a(A/B)
64
0/1
0000
10100
xxxxxx
Address space starts at 0x0500. Selected MIMO channel depends on MAC[1:0].
RxGFIR3b(A/B)
64
0/1
0000
10101
xxxxxx
Address space starts at 0x0540. Selected MIMO channel depends on MAC[1:0].
RxGFIR3c(A/B)
64
0/1
0000
10110
xxxxxx
Address space starts at 0x0580. Selected MIMO channel depends on MAC[1:0].
