Calibration_LowBandBand_TBB
Input Parameters: channel
Return Parameters: status
Return Result.
END
Save current configuration
Select channel
AGC_MODE[1:0](0x040A[13:12])
Perform Algorithm_A_TBB Procedure and get Result
Perform Algorithm_B_RBB Procedure for 11 MHz band,
path 3 and get Result
Perform Algorithm_C_TBB Procedure and get Result
Perform Algorithm_D_RBB Procedure for path 4 and get
Result
Perform Algorithm_E_RBB Procedure for 8.2 MHz band,
path 5 and get Result
Perform Algorithm_E_RBB Procedure for 5.5 MHz band,
path 3 and get Result
Reduce Real Pole RBANK value -50%
Reduce PreEmphasis Zerp by -50%
Perform Algorithm_D_RBB Procedure for path 4 and get
Result
Perform Algorithm_E_RBB Procedure for 2.7 MHz band,
path 5 and get Result
Perform Algorithm_E_RBB Procedure for 2.8 MHz band
and get Result
