Lime Microsystems LMS7002MR3 - Page 70

66
Address (15 bits)
Bits
Description
0x05C1
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
DCCAL_CALSTATUS_RXBQ. RXBQ DC calibration status (Read only):
0 – Calibration is not running
1 – Calibration is running
DCCAL_CALSTATUS_RXBI. RXBI DC calibration status (Read only):
0 – Calibration is not running
1 – Calibration is running
DCCAL_CALSTATUS_RXAQ. RXAQ DC calibration status (Read only):
0 – Calibration is not running
1 – Calibration is running
DCCAL_CALSTATUS_RXAI. RXAI DC calibration status (Read only):
0 – Calibration is not running
1 – Calibration is running
DCCAL_CALSTATUS_TXBQ. TXBQ DC calibration status (Read only):
0 – Calibration is not running
1 – Calibration is running
DCCAL_CALSTATUS_TXBI. TXBI DC calibration status (Read only):
0 – Calibration is not running
1 – Calibration is running
DCCAL_CALSTATUS_TXAQ. TXAQ DC calibration status (Read only):
0 – Calibration is not running
1 – Calibration is running
DCCAL_CALSTATUS_TXAI. TXAI DC calibration status (Read only):
0 – Calibration is not running
1 – Calibration is running
DCCAL_CMPSTATUS_RXBQ. RXBQ comparator value. Used as status source for
manual calibration routines (Read only)
DCCAL_CMPSTATUS_RXBI. RXBI comparator value. Used as status source for
manual calibration routines (Read only)
DCCAL_CMPSTATUS_RXAQ. RXAQ comparator value. Used as status source for
manual calibration routines (Read only)
DCCAL_CMPSTATUS_RXAI. RXAI comparator value. Used as status source for
manual calibration routines (Read only)
DCCAL_CMPSTATUS_TXBQ. TXBQ comparator value. Used as status source for
manual calibration routines (Read only)
DCCAL_CMPSTATUS_TXBI. TXBI comparator value. Used as status source for
manual calibration routines (Read only)
DCCAL_CMPSTATUS_TXAQ. TXAQ comparator value. Used as status source for
manual calibration routines (Read only)
DCCAL_CMPSTATUS_TXAI. TXAI comparator value. Used as status source for
manual calibration routines (Read only)
Default: XXXXXXXX XXXXXXXX
