Lime Microsystems LMS7002MR3 - Page 71

67
Address (15 bits)
Bits
Description
0x05C2
15
14
13
12
11
10
9
8
7
6
5
4
3
2
1
0
DCCAL_CMPCFG_RXBQ. RXBQ comparator configuration
0 – Comparator output not inverted (default)
1 – Comparator output inverted
DCCAL_CMPCFG_RXBI. RXBI comparator configuration
0 – Comparator output not inverted (default)
1 – Comparator output inverted
DCCAL_CMPCFG_RXAQ. RXAQ comparator configuration
0 – Comparator output not inverted (default)
1 – Comparator output inverted
DCCAL_CMPCFG_RXAI. RXAI comparator configuration
0 – Comparator output not inverted (default)
1 – Comparator output inverted
DCCAL_CMPCFG_TXBQ. TXBQ comparator configuration
0 – Comparator output not inverted (default)
1 – Comparator output inverted
DCCAL_CMPCFG_TXBI. TXBI comparator configuration
0 – Comparator output not inverted (default)
1 – Comparator output inverted
DCCAL_CMPCFG_TXAQ. TXAQ comparator configuration
0 – Comparator output not inverted (default)
1 – Comparator output inverted
DCCAL_CMPCFG_TXAI. TXAI comparator configuration
0 – Comparator output not inverted (default)
1 – Comparator output inverted
DCCAL_START_RXBQ. Start automatic DC calibration for RXBQ:
0 to 1 – Start automatic calibration
DCCAL_START_RXBI. Start automatic DC calibration for RXBI:
0 to 1 – Start automatic calibration
DCCAL_START_RXAQ. Start automatic DC calibration for RXAQ:
0 to 1 – Start automatic calibration
DCCAL_START_RXAI. Start automatic DC calibration for RXAI:
0 to 1 – Start automatic calibration
DCCAL_START_TXBQ. Start automatic DC calibration for TXBQ:
0 to 1 – Start automatic calibration
DCCAL_START_TXBI. Start automatic DC calibration for TXBI:
0 to 1 – Start automatic calibration
DCCAL_START_TXAQ. Start automatic DC calibration for TXAQ:
0 to 1 – Start automatic calibration
DCCAL_START_TXAI. Start automatic DC calibration for TXAI:
0 to 1 – Start automatic calibration
Default: 00000000 00000000
0x05C3
15
14
13 – 11
10 – 0
DCWR_TXAI. Used to enable manual write operation of TXAI DAC values. Value
must be first stored in DC_TXAI register prior to toggling this flag:
0 to 1 – writes the value to TXAI DAC from DC_TXAI register Default: 0
DCRD_TXAI. Used to enable manual read operation of TXAI DAC values:
0 to 1 – read the value from TXAI DAC to DC_TXAI register Default: 0
Reserved
DC_TXAI[10:0]: Stores the value to be written to the as well as read value from
TXAI DAC. Default: 0
DC_TXAI[10] – sign
DC_TXAI[9:0] – magnitude
Default: 00000000 00000000
