68
Address (15 bits)
Bits
Description
0x05C4
15
14
13 – 11
10 – 0
DCWR_TXAQ. Used to enable manual write operation of TXAQ DAC values. Value
must be first stored in DC_TXAQ register prior to toggling this flag:
0 to 1 – writes the value to TXAQ DAC from DC_TXAQ register Default: 0
DCRD_TXAQ. Used to enable manual read operation of TXAQ DAC values:
0 to 1 – read the value from TXAQ DAC to DC_TXAQ register Default: 0
Reserved
DC_TXAQ[10:0]: Stores the value to be written to the as well as read value from
TXAQ DAC. Default: 0
DC_TXAQ[10] – sign
DC_TXAQ[9:0] – magnitude
Default: 00000000 00000000
0x05C5
15
14
13 – 11
10 – 0
DCWR_TXBI. Used to enable manual write operation of TXBI DAC values. Value
must be first stored in DC_TXBI register prior to toggling this flag:
0 to 1 – writes the value to TXBI DAC from DC_TXBI register Default: 0
DCRD_TXBI. Used to enable manual read operation of TXBI DAC values:
0 to 1 – read the value from TXBI DAC to DC_TXBI register Default: 0
Reserved
DC_TXBI[10:0]: Stores the value to be written to the as well as read value from
TXBI DAC. Default: 0
DC_TXBI[10] – sign
DC_TXBI[9:0] – magnitude
Default: 00000000 00000000
0x05C6
15
14
13 – 11
10 – 0
DCWR_TXBQ. Used to enable manual write operation of TXBQ DAC values. Value
must be first stored in DC_TXBQ register prior to toggling this flag:
0 to 1 – writes the value to TXBQ DAC from DC_TXBQ register Default: 0
DCRD_TXBQ. Used to enable manual read operation of TXBQ DAC values:
0 to 1 – read the value from TXBQ DAC to DC_TXBQ register Default: 0
Reserved
DC_TXBQ[10:0]: Stores the value to be written to the as well as read value from
TXBQ DAC. Default: 0
DC_TXBQ[10] – sign
DC_TXBQ[9:0] – magnitude
Default: 00000000 00000000
0x05C7
15
14
13 – 7
6 – 0
DCWR_RXAI. Used to enable manual write operation of RXAI DAC values. Value
must be first stored in DC_RXAI register prior to toggling this flag:
0 to 1 – writes the value to RXAI DAC from DC_RXAI register Default: 0
DCRD_RXAI. Used to enable manual read operation of RXAI DAC values:
0 to 1 – read the value from RXAI DAC to DC_RXAI register Default: 0
Reserved
DC_RXAI[6:0]: Stores the value to be written to the as well as read value from RXAI
DAC. Default: 0
DC_RXAI[6] – sign
DC_RXAI[5:0] – magnitude
Default: 00000000 00000000
