60/150 D9U001GKB-0101
Procedure when removing the video colposcope from passive to active
position is evident in the pictures
• During the patient´s sitting down and standing up, the colposcope
must always be parked in passive position under seat.
• Maximum colposcope loading and display holder loading is 2 kg!
Potential collision situation
1. Collision situation of foot support and colposcope body or arm.
Permanent damages to parts of the colposcope can occur.
2. Jam spot between colposcope arm and foot support of doctor. Personal
injury can occur.
