LINET Multicare X - Manipulation

D9U001MCX-0101_03
123
17.7.4 Manipulation
CAUTION!
Damage to i-Drive Power main control panel cable due to wrong cable placement!
► Ensure that the main control panel connecting cable is placed correctly.
CAUTION!
Material damage due to incorrect use!
► Do not hang anything on the main control panel and its cable!
NOTE Each bed can transport only single patient at a time and cannot be used to transport other items (except bed accessories
in secured position).
NOTE For information concerning uses other than those outlined in the “Specications of Use” section above, please contact
LINET ®.
1. Safety Sense (touch sensor)
2. Main Control Panel
3. Main Control Panel Cable – correct cable placement
4. Activation Panel
1
2
3
4
Fig. Position of Main Control Panel
