D9U001MCX-0101_03
23
5 Technical Specication
All technical data are rated data and are subject to construction and manufacturing tolerances.
WARNING!
If Multicare X bed is used with OptiCare X integrated mattress system respect values of mechanical and elect-
rical specications which can harm none of them!
5.1 Identication of Applied Parts (Type B)
All part of the bed (and accessories) the patient can reach are type B Applied Parts.
■ Mattress support platform frame, Covers and all Movable Parts
■ Head Board and Foot Board
■ Siderails
■ Mobi-Lift Handles
■ Handset
5.2 Scales (only version with scales)
Accuracy of displayed weight values:
■ 0,5 kg (1,1 lbs)
■ Scales Class III
5.3 Mechanical Specications (Multicare X)
Parameter Value
External Dimensions in Standard Bed Position (length x width) 215 cm x 105 cm
Maximum Length of Backrest 87,5 cm
Maximum Length of Seat Section 26,5 cm
Maximum Length of Thighrest 36 cm
Maximum Length of Calfrest 38,5 cm
Safety Siderail Height above Mattress support platform 45 cm (maximum)
Dimensions of Head Siderail (length x height) 53,5 cm x 56,5 cm
Dimensions of Foot Siderail (length x height) 100,7 cm x 46 cm
Bed Extension (minimum — maximum) 0 cm — 22 cm
Maximum Dimensions of Mattress (length x width) 214 cm x 87,5 cm
Maximum Mattress Height 23 cm
Clearance in Standard Position 15 cm
Castor diameter 15 cm
Minimum — Maximum Mattress support platform Height above
oor (without Mattress)
44 cm — 82 cm
Ergoframe (Backrest/Thighrest) 6 cm / 6 cm
Maximum Backrest Angle 70°
Maximum Thighrest Angle 30°
Maximum Calfrest Angle 38°
Angle between Calfrest and Thighrest 112°
Maximum Lateral Tilt Angle +30°/-30°
Trendelenburg Angle 13°
Antitrendelenburg Angle 16°
Average Bed Weight (without mattress) 224 kg
Bed Safe Working Load (SWL):
- Patient
- Mattress (OptiCare X)
- Accessories
- Load on the Accessories
250 kg
185 kg
15 kg
13,12 kg
28,6 kg
