D9U001MCX-0101_03
31
Fig. Isolating Foil Placement
8.1 Accumulator Activation
Control Section Placement
Fig. Detail of Isolating Foil
Removing the Isolating Foil
To remove isolating foil:
► Remove isolating foil from mains control box by pulling strap.
► Check if isolating foil is complete and undamaged as shown in gure Detail of Isolating Foil.
► If isolating foil is damaged, contact the manufacturer’s service department immediately.
NOTE Isolating Foil is sharp-edged. Remove it carefully not to cut yourself.
