LINET Multicare X User Manual

D9U001MCX-0101_03
69
Fig. Backrest History Screen
BACKREST
HISTORY
25. 12. 2025 10:00:00 03:30:00
24. 12. 2025 08:42:00 03:30:00
23. 12. 2025 09:00:00 03:30:00
22. 12. 2025 18:30:00 03:30:00
21. 12. 2025 06:00:00 03:30:00
20. 12. 2025 00:00:00 03:30:00
19. 12. 2025 10:00:00 03:30:00
18. 12. 2025 06:12:00 03:30:00
17. 12. 2025 08:44:00 03:30:00
16. 12. 2025 07:00:00 03:30:00
TIME ≥45°TIME ≥30°
DATE
25. 12. 25
22:58
4
5
321
6
1. Column with recorded dates
2. Column with recorded periods during which Backrest was in the angle equal to or greater than 30° up to 44°
3. Column with recorded periods during which Backrest was in the angle equal to or greater than 45°
4. Previous Lines Icon
5. Next Lines Icon
6. Return to the Positioning Screen Icon
