Fig. Base Cover Description
1
3
1
2 2
2 2
1
HEAD END
1. Safety Straps
(to fix mattress on the Matress Platform)
2. Transport Handles
3. Aip Pipes
5.6 Transport Handles
WARNING!
Material damage and risk of injury due to incorrect use!
► Transport the mattress using transport handles without patient on it!
Transport handles are intended for transport of the mattress.
5.7 SCU (System Control Unit)
The SCU (System Control Unit) is installed under the leg section of the bed frame. It is possible to have the Eleganza 5 bed or
Multicare bed delivered with the SCU factory-tted, or to have it retrotted by approved service personnel. OptiCare ready Elegan-
za 5 bed or OptiCare ready Multicare bed are equipped with a dedicated power outlet for the SCU at the auxiliary power distribution
point. The SCU is operated via the Mattress Section on the iBoard Standard. There is no ON/OFF switch on SCU. The SCU is
equipped with a comprehensive alarm system which detects any problems with the system performance.
The alarm system
► gives audible and visual alarms via the iBoard Standard if a problem requires immediate action.
► stores information for the service personnel to review later.
5.7.1 FIRMWARE
The system control unit includes rmware that can be updated only by an authorised service technician.
This rmware is protected against unauthorised access by mechanical housing (tool is needed to access) and by exclusive
compatibility with an authorised software tool and specic cable.
