OptiCare for Eleganza 5
DISCONNECTED AIR PIPES
If either the red, yellow or black air pipe is disconnected from the
System Control Unit the following alert appears on the display.
„MATTRESS DISCONNECTED“ text is scrolling on the display.
NOTE Red triangle with exclamation mark is displayed during
this alert and audio alarm sounds.
NOTE Blue air pipes disconnected from the Sytem Control Unit
do not cause this alert!
To remove this alert:
► check and reconnect each air pipe to the compressor!
CLOSE CPR
When CPR valve is opened and the mattress is inating
this alert appears.
NOTE Red triangle with „USE MANUAL CPR“ text
is displayed during this alert.
To remove this alert:
► close CPR valve manually!
COMPRESSOR (SCU) NOT CONNECTED
When SCU is removed from the bed or communication between
the bed and the SCU is lost this alert appears with
„PUMP DISCONNECTED“ text.
NOTE There is red triangle with exclamation mark on the display
during this alert.
To remove this alert:
► install compressor on the bed!
Fig. DISCONNECTED AIR PIPES
Fig. CLOSE CPR MANUALLY
Fig. PUMP DISCONNECTED
