System Management
Linksys
Service: This is to select the Binding Service Port to be activated.
The default (such as ALL-TCP&UDP 0~65535, WWW
80~80, FTP 21 to 21, etc.) can be selected from the pull-
down option list. The default Service is All 0~65535.
Option List for Service Management: Click the button
to enter the Service Port configuration page to add or
remove default Service Ports on the option list.
Source IP: Users can assign packets of specific Intranet virtual IP to
go through a specific WAN port for external connection.
In the boxes here, input the Intranet virtual IP address
range; for example, if 192.168.1.100~150 is input,
the binding range will be 100~150. If only specific
Service Ports need to be designated, while specific IP
designation is not necessary, input “0” in the IP boxes.
Destination IP: In the boxes, input an external static IP address. For
example, if connections to destination IP address
210.11.1.1 are to be restricted to WAN1, the external
static IP address 210.1.1.1 ~ 210.1.1.1 should be input. If
a range of destinations is to be assigned, input the range
such as 210.11.1.1 ~ 210.11.255.254. This means the
Class B Network Segment of 210.11.x.x will be restricted
to a specific WAN. If only specific Service Ports need to be
designated, while a specific IP destination assignment is
not required, input “0” into the IP boxes.
Interface: Select the WAN for which users want to set up the
binding rule.
Enable: To activate the rule.
Add To List: To add this rule to the list.
Delete To remove the rules selected from the Service List.
Moving Up & Down: The priority for rule execution depends on the rule order
in the list. A rule located at the top will be executed prior
to those located below it. Users can arrange the order
according to their priorities.
Add New: Click the button to start a new entry.
Note The rules configured in Protocol Binding will be executed by the device
according to their priorities too. The higher up on the list, the higher the priority
of execution.
Adding a service
To add a new service item or to edit an existing service, click Service
Management. If the web browser displays a warning about the pop-up
window, click to allow the blocked content.
In the Service Management window, add or edit entries as needed. After setting
a rule, be sure to click OK to save your settings or click Cancel to undo them. To
add a service to the list: Enter the following information, and then click Add to
List. You can have up to 30 services in the list.
o Service Name: Give a name to the service.
o Protocol: Choose the required protocol. TCP, UDP or Ipv6 can be chosen.
o Port Range: Enter the port range.
• To add another new service: Enter the information, and then click Add
to list.
• To edit a service you created: Select the service in the list and then click
Update to make the changes. If you do not need to make changes, click
Add New to de- select the service and clear the text fields.
• To delete a service from the list : Click Delete to delete an existing service.
