QUICK LOAD SERVO 80 S2
The bar feed system is always delivered as follows :
· Magazine (A) is assembled on the bar feed system.
· The retraction mechanism (B) is supplied partly or completely assembled, depending the moving
side ordered.
· A feeding pusher is supplied mounted on.
The additional pushers, are affixed under the loading table.
· The notice instruction and the accessories are delivered in a separate package (C).
· The bar feed system is held on the pallet by bolts and nuts.
Take out the parts, and place them in an easily accessible area for mounting the
bar feed system.
