CHAPTER 5: GENERAL DESCRIPTION 55
QUICK LOAD SERVO 80 S2
Tubing
With regard to loading the tubing, standard feeding pushers
may be used as long as the inside diameter of the tubes is
smaller than the outside diameter of the pushers.
If this is not the case, caps (A) to be installed into the tubes
(B) must be manufactured.
For the caps to stay in place while the bar is rotating, they
should befitted with an O-Ring.
