LNS QUICK SIX - Recommended Spare Parts List

6-2 Chapter 6: Spare Parts
QUICK SIX
Recommended Spare Parts List
As an extended courtesy, a list of recommended spare parts has been compiled for the end user. The list consists of mechanical and
electrical parts that over time may become faulty due to everyday wear on the item. For machines that are running production during
multiple shifts or even 24/7, keeping an inventory of these spare parts can vastly minimize downtime. Keeping an inventory can also
be very cost effective since shipping costs can escalate immensely, especially in cases where rush delivery is necessary.
Qty. Order # Part # Description
MECHANICAL
1 3.348 3.348-A Air regulator
1 023.30.164 822-008.A 8mm pusher tip
1 023.30.094 822-015.A 15mm tightening sleeve
1 023.30.104 822-015.B 15mm pusher tip
1 11.002 822-015.C 15mm coupling for pusher tip
1 023-030-043 822-008 8mm pusher assembly
1 023-030-033 822-015 15mm pusher assembly
ELECTRICAL
1 4.772 4.772 SQ1 & SQ12 photo eye
1 4.790 822-019 SQ3, 4, 5, 6, 8, 9 proximity switch
1 4.391 4.391 SQ2, 7,13, 15 proximity switch
1 4.484 4.484 SQ10, 17, 18 proximity switch
1 4.808 822-020.A SQ16 absolute encoder
1 4.773 4.773 SQ12 reflector
1 4.050 4.050-A SP2 pressure switch
When ordering parts, to ensure better customer support, please specify the following
information:
Type of bar feeder, bar feeder serial number, bar stock diameter, and lathe type (refer to
Parts
Order Form pg. 6-3)
Spindle Liners
Ensure that the properly sized spindle liner has been installed (matches guiding channel size).
Ensure that the spindle liner is straight (check total run out).
Ensure that the liner is securely fastened.
