Chapter 1: Alarms
QUICK SIX
1-19
A045 – Bar Magazine Indexing Motor Faulty
BAR MAGAZINE
INDEXING MOTOR
FAULTY !
POSSIBLE CAUSES :
-DC MOTOR DEFECTIVE
-LOCKED MECHANISM
-PROXIMITY SWITCH
SQ2 FAULTY
A045
Description:
The Bar Magazine Indexing Motor Faulty alarm is generated during the loading sequence when the output for the indexing motor (M5)
is active and the state of the input (I1.0 – SQ2), bar magazine diameter adjustment proximity switch, does not change.
Solution:
Alarm needs to be cleared. Press the STOP key on the remote control station to clear the message and reset the alarm.
• Make sure that the SQ2 switch is adjusted to within 0.5mm-1mm from the chain fingers.
• Check that the motor is operational.
If the problem persists please contact LNS America, Inc. for further information.
