A116 – Bar Stock Loading Error
BAR STOCK LOADING
ERROR!
POSSIBLE CAUSES:
- MAGAZINE EMPTY
- BAR SELECTION
DEVICE MIS-ADJUSTED
- GUIDING CHANNEL
EMPTY DUE TO
MIS-LOADING
A116
Description:
The Bar Stock Loading Error alarm occurs if input (I1.2 – SQ3) is still active after the loading flag returns home after positioning the
new bar into the spindle for top-cut. This alarm is also generated during the loading cycle if input (I1.2 – SQ3) does not detect a new
bar and the v-channel drops to the lower position.
Solution:
Press the STOP key on the remote control station to clear the message and reset the alarm. Press the HELP key. Press F4 (Page
Down icon) twice.
Case Input Remote Pendant Solution
1 Bit 2 = 1
MODULE 1
76543210
100
• Check that the loading flag is pushing the new bar past the
measuring cell (SQ3).
2 Bit 2 = 0
MODULE 1
76543210
0
• Load bar stock onto the magazine rack.
• Check that the loading fingers are set to pick up a single bar.
