LNS QUICK SIX - A012 - Bar Magazine Indexing Interrupted

1-12 Chapter 1: Alarms
QUICK SIX
A012 – Bar Magazine Indexing Interrupted
BAR MAGAZINE
INDEZING
INTERRUPTED!
POSSIBLE CAUSES:
- REFLECTIVE SENSOR
OBSTRUCTED
- REFLECTIVE SENSOR
MISALIGNED
- REFLECTIVE SENSOR
DEFECTIVE A012
Description:
The Bar Magazine Indexing Interrupted alarm occurs when the loader rack is indexing and the input signal (I2.0 – SQ12) turns off.
Solution:
Case Input Remote Pendant Solution
1 Bit 2 = 1
MODULE 2
76543210
1
Alarm needs to be cleared. Press the STOP key on the remote
control station to clear the message and reset the alarm.
Check to see if there is any obstruction interfering with the reflector.
Make sure that the SQ12 switch is adjusted and aligned correctly.
2 Bit 2 = 0
MODULE 2
76543210
0
If the input still does not turn on, the problem can be isolated to a
defective switch or defective cable. Replace the cable and switch.
For case 2, after the solution has been completed, press the STOP key on the remote control station to clear the message and reset
the alarm.
