Chapter 3: Procedures
QUICK SIX
3-3
Step 8: Once the belt tension is adjusted correctly, tighten the jam nut.
Tighten jam nut
Step 9: Tighten the 17mm fixed hex nut.
Loosen fixed
hex nut
Procedure complete.
