Chapter 1: Alarms
QUICK SIX
1-3
Desi
g
nation Descri
p
tion
A Remote control station
B Control cabinet
C Optional interface cable outlet
M1 Hydraulic pump motor
M2 Servo motor
M3 Motor dropping fingers
M5 Motor bar loader
QS1 Main disconnect switch
SP1 Pneumatic pressure switch
SP2 Hydraulic pressure switch
SQ1 Positioning stopper proximity switch
SQ2 Bar stock presence proximity switch
SQ3 Opening guiding channel control switch
SQ4 Closing guiding channel control switch
SQ5 Bearing blocks 1 open
SQ6 Bearing blocks 2 closed
SQ7 Control switch: pusher in rear/park position
SQ8 Bearing blocks 2 open
SQ9 Bearing blocks 1 closed
SQ10 Retraction system in position switch (option)
SQ11 Main access cover safety switch
SQ12 Magazine safety switch – transmitter / deflector
SQ14 Dropping fingers up
SQ15 Proximity switch dropping fingers 0-point
SQ16 Signal A (Encoder)
SQ17 Control switch main cover closed
SQ18 Dropping fingers safety
STP Emergency stop
