ZENIT
TECHNICAL DATA
Technical Data (Changes reserved!)
System
Concept Modular, integrated in winder / Components individually replaceable / Power supply by winder
Control station One control station per machine / Date and time indication / Data memory in case of power failure /
Serial connection to industrial PC and to evaluation units
Operating Setting of the conventional clearing parameters via touch screen
Operating temperature +5° up to +50° C
Humidity Up to max. 95% relative humidity not condensing
Evaluation unit 1 AWE per spindle or per 2 spindles (depending on the machine type)
integrated in the electronics box of the spindle control
Sensing head 1 TK per spindlel
Range of application For staple-spun yarn of natural, synthetic or metal fibers
Central Unit (LZE)
ZE YM ZENIT Graphics-capable display backlit and keyboard, touch screen
Connection M21C / Espero / Espero Nuovo / VJ Excello / Smaro
EJP 438 / DTM 439 / Spero 90 –264 V AC
Orion / Polar 24 V DC +/- 10%
AC238 85-132 V AC / 187-550 V AC
Max. power consumption Typical power consumption 30 Watt, depending on the machine type
Capacity of winder Up to 80 yarn clearers can be connected, depending on the machine type
Groups Up to 12 yarn qualities, depending on the machine type
Dimension Ca. 483 x 266 x 120 mm (B x H x T)
Weight Approx. 6.0 kg
Printing Printout (PDF) via USB stick
Evaluation Unit (AWE)
AWE YM ZENIT Orion / Polar / M21C / Smaro / Spero / AC 238 / EJP 438 / DTM 439 1 AWE for 1 spindle
Espero i / Espero Nuovo / VJ Excello 1 AWE for 2 spindles
Max. power consumption Orion / Polar / M21C / Smaro / Spero / AC 238 / EJP 438 / DTM 439 Max. 5 Watt, depending on TK type
Espero i / Espero Nuovo / VJ Excello 5 –8 Watt, depending on TK type
Winding speed Up to 2000 m/min
Sensing Head (TK) Yarn Count Range (Optical scanning principle)
ZENIT ZENIT F ZENIT FP
TK Type Limit Range Coarse Limit Range Fine
TK YM ZENIT C
Nm 4.0 – 10.0 / Nec 2.4 – 5.9 Nm 430 – 540 / Nec 255 – 320
* * *
TK YM ZENIT F C Nm 7.0 – 10.0 / Nec 4.1 – 5.9 Nm 430 – 540 / Nec 255 – 320
* *
TK YM ZENIT FP C Nm 7.0 – 10.0 / Nec 4.1 – 5.9 Nm 430 – 540 / Nec 255 – 320
*
TK YM ZENIT FP2 C Nm 7.0 – 10.0 / Nec 4.1 – 5.9 Nm 430 – 540 / Nec 255 – 320
*
All sensing heads are also available as wet-splice versions.
