Installing the Camera(s)
3
3.2 Mounting Positions
You may mount your cameras on a wall or ceiling. See the images below for recommended
configurations of the camera stand and antenna.
Wall
Ceiling
NOTE
For ceiling installation, position the antenna as high as the ceiling allows. See the "Ceiling" mounting posi-
tion in the figure above.
#LX400069; r.28523/28523; en-US
6
