7.2 Understanding the On-screen Display
With camera 1 properly connected and powered on, the system displays a full-screen live
view of the camera.
With more than one camera properly connected and powered on, the system displays up
to 4 channels in split screen with the live view of each camera. The figure below shows the
display configuration for 2 cameras connected.
