Camera Overview
5
1. Microphone: Built-in microphone.
2. Lens: Camera lens.
3. PIR Sensor: Passive IR motion sensor.
4. Speaker: Speaker for intercom.
5. IR LEDs: Night vision IR LEDs.
6. Pair: Pairing button. For more details, see 17 Pairing Additional Cameras, page 49.
7. Antenna: Removable wireless antenna (SMA type).
NOTE
This camera includes an Auto Mechanical IR Cut Filter. When the camera changes between day mode
and night vision mode, an audible clicking noise may be heard coming from the camera. This clicking is
normal, and indicates that the camera filter is working.
#LX400069; r.28523/28523; en-US
12
