Technical Specifications
20
20.1 General
Description Specification
Transmission Frequency 2,400 ~ 2,483.5MHz
Transmission Power 16dBm
Data Rate 4 Mbps
Unobstructed Wireless Range
660ft (200m) outdoors / 165ft (50m)indoors
Spread Spectrum FHSS
Modulation GFSK
Operating Humidity
≤ 85%
20.2 Camera
Description Specification
Image Sensor 1/4" CMOS Image Sensor
Supported Resolution 720p (1280x720) up to 25/30fps
Minimum Illumination
< 5Lux (IR on) / > 30Lux (IR off)
AGC
Auto
AES Speed 1/30 (1/25) ~1/1000 Second
IR LEDs 24 pieces
Night Vision Range 65ft (20m) / 45ft (14m)
PIR Range 16ft (4.9m)
Lens / Lens Type
3.6mm F2.0
View Angle Horizontal 58°
Power Consumption Max 425mA (IR on)
Power Supply 9V DC 600mA ±10%
Operating Temperature 14 ~ 122°F / -10 ~ 50°C
Dimensions (W x D x H) 5.4 x 7.4 x 4.9”
137 x 187 x 124mm
Weight 0.60lbs / 0.20kg
20.3 Receiver
Description Specification
Display 7” diagonal
LCD Resolution
800x480
Supported Resolutions 720p (1280x720) up to 15 fps
VGA (640x480) up to 25/30 fps
QVGA (320x240) up to 25/30 fps
Image Processing
MPEG4
Battery 2000mAh 3.7V
Power Consumption Max 800mA
Power Supply 5V/2A DC ±10%
Operating Temperature 32 ~ 104°F / 0 ~ 40°C
#LX400069; r.28523/28523; en-US
66
