Page #46 background imageLoading...
Page #46 background image
44 The GS550 System
2.11.1 Recording Modes
Adjust the data logger recording mode as required:
1. Press Menu, and then Next three times.
2. Press Enter, Next five times, and then Enter to go to menu 4F1) Data logger mode
3. Use Up and Down to select the data logger recording mode.
4. Automatic modes only: press Next to advance to the adjustment page for the interval (auto-
matic recording mode), variation (automatic variation recording mode), or threshold (automatic
peak recording mode).
5. Press Enter to save any changes.
6. Press Exit three times to return to the operation display or press Next to adjust the data logger
date and time (see below).
Tip
All alerts are recorded by the data logger regardless of the mode selected.
Alarm only. Record alarms only. All the other data logger modes also record alarms.
Automatic recording. A record is added at a specified interval. When the automatic re-
cording data logger mode is selected on menu page 4F1 (see step 4 above) press Next to
go to page 4F11) and then use Up and Down to adjust the record interval in minutes.
Important!
Wind speed: the data logger recording mode must be set to automatic recording to log the
data required by the wind speed report feature of the Data Logger Viewer software.
Automatic variation. A record is added when load increases by more than the operator
adjusted percentage. When the automatic variation data logger mode is selected on menu
page 4F1 (see step 4 above) press Next to go to page 4F11) and then use Up and Down
to adjust the variation threshold.
Automatic peak. In the automatic peak mode the data logger analyzes the measured
weight and records the peak value only. One threshold per load cell must be adjusted.
When the weight drops by more than the peak threshold the peak weight is recorded. Only
one event is recorded for each pick when the threshold is adjusted correctly. When the
automatic peak data logger mode is selected on menu page 4F1 (see step 4 above) press
Next to go to page 4F11) and then use Up and Down to adjust the peak threshold for the
first load cell. Press Next to repeat for the second load cell etc. Up to four load cells can be
programmed for automatic peak data logging.
User input. Available on request only, the status of all sensors is recorded on demand. A
custom hardware modification to the GS550 display is required and a normally open push
button must be installed on a digital input to the GS550 through a pre-determined wire of
the power supply and lockout cable.
All data. All communications between a display and its sensors are recorded.
2.11.2 Date and Time
Adjust the data logger date and time as required:
1. Press Menu, and then Next three times.
