2. Operation 45
2. Press Enter, and then Next five times.
3. Press Next, Enter and Next to go to menu 4F2) Adjust date.
4. The last two digits of the year should be flashing: use Up and Down to adjust the year.
5. Press Next to adjust the month.
6. The month should be flashing: Use Up and Down to adjust the month.
7. Press Next to adjust the day.
8. The day should be flashing: use Up and Down to adjust the day.
9. Press Next to adjust the time.
10. The hour should be flashing: use Up and Down to adjust the hour from 00 (midnight) to 23 (11
pm).
11. Press Next to adjust the minute.
12. The minute should be flashing: use Up and Down to adjust the minute.
13. Press Next to adjust the second.
14. The second should be flashing: use Up and Down to adjust the second.
15. Press Enter to save any changes.
16. Press Exit three times to return to the operation display.
2.12 The Sensor List
All sensors in the GS550 system are programmed in the sensor list. The GS550 uses information
from all sensors in the sensor list. Conversely the GS550 will not use or display information from
sensors that are not programmed to the sensor list. If a sensor is removed from the crane then it
must be removed from the sensor list. If a sensor is replaced the sensor list must be updated with
the new id number.
Warning!
Information display from load, angle and boom length sensors that are not correctly in-
stalled will not be accurate.
Rated capacity, radius, and tip height based on information from angle and boom length
sensors that are not correctly installed will not be accurate.
2.12.1 How to Add a Sensor to the GS550
1. Determine the radio identification number (id) of the sensor to be added. This number between
10000 and 99999 is engraved on the sensor.
2. Press Menu, and then Next three times.
3. Press Enter twice to go to menu page 4A1) (see Figure 24).
Tip
To ensure communication sensors must be at least six feet from the GS550 display.
