Lucent Technologies DDM-2000 OC-12 User Manual

363-206-295
Administration and Provisioning
Issue 1 December 1997 8-19
Table 8-6. DDM-2000 OC-12 Manual STS-1 Cross-Connections (Rings Drop and
Continue)
Table 8-7. DDM-2000 OC-12 Manual STS-3c Cross-Connections (Rings Drop and
Continue)
Table 8-8. DDM-2000 OC-12 Manual STS-3c Cross-Connections (RTV)
From To “To” CP Type Example Command *
mb-{1-12} <--> a-{1-3} 3STS1E, 3DS3, OLIU ent-crs-sts1:mb-1,a-1:cct=dc,ring=mb1
mb-{1-12} <--> b-{1-3} 3STS1E, 3DS3, OLIU ent-crs-sts1:mb-2,b-3:cct=dc,ring=mb1
mb-{1-12} <--> c-{1-3} 3STS1E, 3DS3, OLIU ent-crs-sts1:mb-3,c-2:cct=dc,ring=mb2
mb-{1-12} <--> d-{1-3} 3STS1E, 3DS3, OLIU ent-crs-sts1:mb-4,d-2:cct=dc,ring=mb2
∗ The "ring" parameter defines the ring carrying the continue signal. This ring connects
to the other drop and continue shelf.
From To “To” CP Type Example Command *
mb-{1,4,7,10} <--> a-1 21-type OLIU ent-crs-sts3c:mb-1,a-1:cct=dc,ring=mb1
mb-{1,4,7,10} <--> b-1 21-type OLIU ent-crs-sts3c:mb-4,b-1:cct=dc,ring=mb1
mb-{1,4,7,10} <--> c-1 21-type OLIU ent-crs-sts3c:mb-7,c-1:cct=dc,ring=mb2
mb-{1,4,7,10} <--> d-1 21-type OLIU ent-crs-sts3c:mb-10,d-1:cct=dc,ring=mb2
∗ The "ring" parameter defines the ring carrying the continue signal. This ring connects to
the other drop and continue shelf.
From To “To” CP Type Example Command
mb-{1,4,7,10} <--> a-1 21-type OLIU ent-crs-sts3c;mb-1,a-1:cct=rtv
mb-{1,4,7,10} <--> b-1 21-type OLIU ent-crs-sts3c;mb-4,b-1:cct=rtv
mb-{1,4,7,10} <--> c-1 21-type OLIU ent-crs-sts3c;mb-7,c-1:cct=rtv
mb-{1,4,7,10} <--> d-1 21-type OLIU ent-crs-sts3c;mb-10,d-1:cct=rtv
