Lucent Technologies DDM-2000 OC-12 User Manual

363-206-295
Administration and Provisioning
8-18 Issue 1 December 1997
Table 8-4. DDM-2000 OC-12 Manual STS-1 Cross-Connections (Rings Pass-Through)
Table 8-5. DDM-2000 OC-12 Manual STS-3c Cross-Connections (Rings Pass-Through)
From To “To” CP Type Example Command *
mb-1 <--> mb-1 23-type OLIU ent-crs-sts1:mb-1,mb-1
mb-2 <--> mb-2 23-type OLIU ent-crs-sts1:mb-1,mb-2
mb-3 <--> mb-3 23-type OLIU ent-crs-sts1:mb-1,mb-3
mb-4 <--> mb-4 23-type OLIU ent-crs-sts1:mb-1,mb-4
mb-5 <--> mb-5 23-type OLIU ent-crs-sts1:mb-1,mb-5
mb-6 <--> mb-6 23-type OLIU ent-crs-sts1:mb-1,mb-6
mb-7 <--> mb-7 23-type OLIU ent-crs-sts1:mb-1,mb-7
mb-8 <--> mb-8 23-type OLIU ent-crs-sts1:mb-1,mb-8
mb-9 <--> mb-9 23-type OLIU ent-crs-sts1:mb-1,mb-9
mb-10 <--> mb-10 23-type OLIU ent-crs-sts1:mb-1,mb-10
mb-11 <--> mb-11 23-type OLIU ent-crs-sts1:mb-1,mb-11
mb-12 <--> mb-12 23-type OLIU ent-crs-sts1:mb-1,mb-12
∗ Cross-connection type is not entered because default is twoway. Address on the left side
MUST BE identical to the address on the right side. There is no interchange function for
"pass-through" signals.
From To “To” CP Type Example Command *
mb-{1,4,7,10} <--> mb-{1,4,7,10} 23-type OLIU ent-crs-sts3c:mb-7,mb-7
∗ Cross-connection type is not entered because default is twoway. Address on the left
side MUST BE identical to the address on the right side. There is no interchange
function for "pass-through" signals.
